Ducted Fume Hood FH(A)

Name: Ducted Fume Hood FH(A)
Brand: Biobase
Availability: InStock

$0.00 SGD

Sale Sold out

Quantity

Fume Hood is a kind of negative pressure ventilation system for protecting operator and laboratory environment. Room air flows inward from the front opening of the Fume Hood and is consistently ventilated by the extract blower. Therefore, contaminated fumes, vapors, toxic gasses, aerosol and corrosive substance which are probably generated during experiments could be prevented from spreading to the operator or into the laboratory room. In addition, the polluted air could be purified by the active carbon filter (optional) before exhausting through the duct. Thus, the outdoor environment could also be protected.

Features:
1. UV lamp for sterilization.
2. Resistant to weak acid and alkali.
3. Adjustable air speed: 9 levels.
4. Motorized front window, height adjustable.
5. Microprocessor control system, LED display.
6. With memory function in case of power-failure.

Technical Parameters:

Model		FH1000(A)	FH1200(A)	FH1500(A)	FH1800(A)
External Size(WDH)		10408002200mm	12408002200mm	15408002200mm	18408002200mm
Internal Size(WDH)		820670730mm	1020670730mm	1320670730mm	1620670730mm
Work Surface Height		850mm
Max Opening		520mm
Air Velocity		0.3~0.8m/s
Exhaust Air Volume		590m³/h	730m³/h	950m³/h	1170m³/h
Noise		≤68dB
Exhaust Duct		PVC, Standard length: 4 meters
		Φ300mm
LED Lamp		8W*1	12W*1	16W*1	16W*1
UV Lamp		Emission of 253.7 nanometers for most efficient decontamination
Blower		Built-in centrifugal blower, Speed adjustable
Front Window		5mm toughened glass, Motorized, Height adjustable
Power Supply		AC220±10%, 50/60Hz; 110V±10%, 60Hz
Consumption		400W	400W	500W	500W
Material	Exterior	Cold-rolled steel with anti-bacteria powder coating
	Interior	Compact laminate board with good acid and alkali resistance function
	Work Table	Chemical resistant phenolic resin
Standard Accessory		UV lamp*2, LED lamp, Water tap, Gas tap, Water sink, Base cabinet
		Total load of 2 waterproof sockets: 500W
		4.3 meters PVC exhaust duct, pipe strap*2
Optional Accessory		Active carbon filter, HEPA filter
Gross Weight		286kg	317kg	350kg	400kg
Package	Main Body	11909901690mm	13909901690 mm	16909901690mm	19909901690mm
	Base Cabinet	1190990900mm	1390990900mm	1690990900mm	1990990900mm

Model		FH1000(A)	FH1200(A)	FH1500(A)	FH1800(A)
External Size(WDH)		10408002200mm	12408002200mm	15408002200mm	18408002200mm
Internal Size(WDH)		820670730mm	1020670730mm	1320670730mm	1620670730mm
Work Surface Height		850mm
Max Opening		520mm
Air Velocity		0.3~0.8m/s
Noise		≤68dB
Exhaust Duct		PVC, Standard length: 4 meters
		Φ300mm
LED Lamp		8W*1	12W*1	16W*1	16W*1
UV Lamp		Emission of 253.7 nanometers for most efficient decontamination
Blower		Built-in centrifugal blower, Speed adjustable
Front Window		5mm toughened glass, Motorized, Height adjustable
Power Supply		AC220±10%, 50/60Hz; 110V±10%, 60Hz
Consumption		400W	400W	500W	500W
Material	Exterior	Cold-rolled steel with anti-bacteria powder coating
	Interior	Compact laminate board with good acid and alkali resistance function
	Work Table	Chemical resistant phenolic resin
Standard Accessory		UV lamp*2, LED lamp, Water tap, Gas tap, Water sink, Base cabinet
		Total load of 2 waterproof sockets: 500W
		4.3 meters PVC exhaust duct, pipe strap*2
Optional Accessory		Active carbon filter, HEPA flter
Gross Weight		286kg	317kg	350kg	400kg
Package	Main Body	11909901690mm	13909901690mm	16909901690mm	19909901690mm
	Base Cabinet	1190990900mm	1390990900mm	1690990900mm	1990990900mm

Note: Pls Add to Quote for a quotation. Do Not "Add to Cart"
